High-precision casting of aluminum alloy products

Manufacture of lightweight and durable aluminum castings with high dimensional accuracy and surface quality for various industries.

Composition

General product description

Manufacture of lightweight and durable aluminum castings with high dimensional accuracy and excellent surface quality for use in various industries. The production process is based on advanced die casting and precision sand casting technologies, which ensures an optimal combination of strength and lightness of the finished products. High-quality aluminum alloys of the AK and AL series and foreign equivalents are used, guaranteeing mechanical characteristics and corrosion resistance.

Capabilities

Applications and capabilities

Applications and capabilities

The castings are used in the automotive industry (housing parts, brackets), the aerospace industry (mounting units, instrument housings), power engineering (heat exchangers) and mechanical engineering (gears, pump housings). Technological capabilities include: production of thin-walled castings (from 2 mm); casting of parts with complex geometry with minimal machining allowances; application of protective coatings; heat treatment to improve mechanical properties. Maximum casting dimensions are 1000×800×500 mm with a weight of up to 50 kg.

Advantages

Key advantages of production: dimensional accuracy of grade 8–10 (ISO 8062); surface roughness Ra 3.2–6.3 µm; weight reduction of parts by 30–50% compared with steel equivalents; high repeatability of parameters (±0.1 mm per 100 mm); shorter production times thanks to minimal machining. Modern CNC equipment and computer simulation systems for casting processes ensure stable quality of every batch.

Deployment

Additional information

Additional information

The full production cycle includes: 3D modeling and analysis of casting processes; manufacture of molds and tooling; casting; heat treatment; quality control (radiography, ultrasonic testing). Design refinement services are provided to optimize the casting technology. Finished products undergo 100% geometry inspection on coordinate measuring machines and can be supplied with machining to IT6–IT8 grades. Order lead time is from 15 working days depending on the complexity of the casting.
